| Specifications Downloadable PDF file | 3300 Track Mount | 1100 Track Mount |
|---|---|---|
| Track Length: | 14' 7" (175") | 11' 5" |
| Transport Height | 13' (156") | 11' 10" (142) |
| Drill Height: | 44' (528") | 39' 4" |
| Track Width: | 10' 9" (117") | 8' 6" |
| Drill Weight: | 46,000 lbs | 44,840 lbs |
| Torque: | 37,000 ft/lbs | 45,000 lbs |
| Maximum Depth: | 93' (1116") | 50' 0" |
| Maximum Hole Diameter: | 6' (72") | 6' (72") |
| Minimum Hole Diameter | 12" | 10" |
| Maximum Reach- Front/Back of Track: | 6' 4" (76") | 4' 6" |
| Maximum Reach-Side of Track: | 6' 6" (78") | 5' 11" |
| Maximum Rotary Height: | 7' 11" (95") | 6' 9" (81") |
| Minimum Working Radius: | 22' (265") | 18' 3" |
