| Specifications Downloadable PDF file | LM55 | EDT5 |
|---|---|---|
| Track Width: | 8' 6" (102") | 11’ 2” (134”) |
| Track Length: | 13' (156") | 15’ 3” (183”) |
| Full Length of Machine: | 27' (324") | 41’ 5” (497”) |
| Minimum Mast Height w/o Tool: | 17' 1" (205") | 18’ 6” (222”) |
| Maximum Drill Depth: | 45' (540") | 65' (780") |
| Maximum Hole Diameter: | 60" | 84" |
| Minimum Hole Diameter: | 12" | 18" |
| Maximum Reach-Front/Back of Track: | 12' 6" (150") | 15’ 0” (180”) |
| Maximum Reach-From Side of Track: | 14' 6" (174") | 17’ 8” (212”) |
| Maximum Torque: | 18,000 ft/lbs. | 43,000 ft/lbs. |
| Base/Track Type: | John Deere 160 | Caterpillar 324 EL |
| Weight: | 48,700 lbs. | 82,000 lbs. |
| Working Radius: | 23' 6" (282") | 26' 8" (330") |
| Extendable Reach: | n/a | n/a |
